Product Name

Packaging form

Pin arrangement

Typical parameters

Download

Icm（A）

BVce0（V）

BVcb0（V）

HFE

General atmospheric pressure series

13001A

TO-92

ECB

0.4

400

650

15-30

13001

TO-92

ECB

0.5

400

650

15-30

13002

TO-92

BCE

0.8

400

700

15-30

13002A

TO-92

BCE

1.2

400

700

15-30

13003

TO-92

BCE

1.5

400

700

15-30

13003D

TO-92

BCE

1.4

400

700

15-30

13003A

TO-92

BCE

1.8

400

700

15-30

13003AD

TO-92

BCE

1.8

400

700

15-30

13003F

TO-126

BCE

1.2

400

700

15-30

13003E

TO-126

BCE

1.5

400

700

15-30

13003D

TO-126

BCE

1.8

400

700

15-30

13003C

TO-126

BCE

2.0

400

700

15-30

13003B

TO-126

BCE

2.2

400

700

15-30

13003A

TO-126

BCE

2.4

400

700

15-30

D13003C

TO-126

BCE

2.0

400

700

15-30

D13003D

TO-126

BCE

1.8

400

700

15-30

D13003A

TO-126

BCE

2.4

400

700

15-30

S13003D

TO-126

BCE

1.8

400

700

15-30

13005S

TO-220

BCE

2.2

400

700

15-30

13005MD

TO-220

BCE

2.3

400

700

15-30

13005A

TO-220

BCE

4

400

700

15-30

High voltage series

13001A-F

TO-92

ECB

0.4

480

650

15-30

13001-F

TO-92

ECB

0.5

480

650

15-30

13001b

TO-92

BCE

0.5

480

650

15-30

BU102S

TO-92

BCE

0.8

480

700

15-30

BU102

TO-92

BCE

1.2

480

700

15-30

13003S

TO-92

ECB

0.8

480

700

15-30

13003e

TO-92

ECB

1.2

480

700

15-30

13003G

TO-126

BCE

1.0

480

700

15-30

13003F-F

TO-126

BCE

1.2

480

700

15-30

13003H

TO-126

BCE

0.5

480

700

15-30

13003H-F

TO-126

BCE

0.45

480

700

15-30

3150H

TO-126

ECB

1.3

500

800

15-30

3160H

TO-126

ECB

1.5

550

850

15-30

1N80

TO-251

BCE

1.2

480

700

15-30

SVD1N60P

TO-251

ECB

1.2

480

700

15-30

DK53

TO-251

BCE

1.7

480

700

15-30

Low voltage series

13003AL TO-92 ECB 1.5 200 400 15-30

Other

D882M

TO-126

ECB

3

30

40

100-400

B772P

TO-126

ECB

3

30

40

100-400
